  1. Free-Hanging Air Cleaners #1

  Filter-1 Model AC-6-85-7.5 (Free-Hanging) Air Cleaner collecting weld smoke at a trailer manufacturing area.
•

  2. Free-Hanging Air Cleaners #2

  Filter-1 Model AC-6-85-7.5 (Free-Hanging) Air Cleaner collecting weld smoke at a trailer manufacturing area.
•

  3. Ambient Air Cleaners #1

  Filter-1 Model AC-4-60-5 ambient Air Cleaner collecting welding smoke in a pipe manufacturing area.
•

  4. Ambient Air Cleaners #2

  (4) Filter-1 Model AC-4-60-5 ambient Air Cleaner collecting welding smoke in a pipe manufacturing area.
•

  5. Weld Smoke Boom, Arm, and Blower

  Airflow Systems 10ft Boom with a 14ft Flexible Arm connected to a 3 HP Motor/Blower Assembly collecting weld smoke out of the breathing zone of the welder.
•

  6. Collector for Welding Bays & Plasma Table #1

  Airex DCCH-30 dust collector connected to (4) Airflow Systems EZ arms in welding bays and (1) 8 x 10 plasma table to collect smoke.
•

  7. Collector for Welding Bays & Plasma Table #2

  Four Airflow Systems 10 boom arm and 10 EZ arm combinations collecting welding smoke.
•

  8. Collector for Welding Bays & Plasma Table #3

  One (8 x 10) down-draft plasma table is connected to an Airex DCCH-30 dust collector to collect smoke.
•

  9. Weld Smoke Extraction Arm With Boom

  Airflow Systems 5-ft. boom with a 10-ft. flexible extractor arm assembly connected to a 3hp motor/blower assembly for collection and ventilation of weld smoke.
•

  10. Self-Cleaning Cartridge Collector for Welding

  Airflow Systems model HC-4-EXHE 2000 cfm self-cleaning cartridge collector with external HEPA final filter and dual 14 ft source capture arms for the collection of welding smoke.
•

  11. Portable Collector With Dual Arms

  Airflow Systems Model PCH-2 portable air cleaner with dual arms collecting welding smoke.
•

  12. Ambient Weld Smoke Collectors #1

  Filter-1 model AC-8 free hanging ambient weld smoke collector collecting welding smoke from manufacturing area.
•

  13. Ambient Weld Smoke Collectors #2

  Filter-1 model AC-8 free hanging ambient weld smoke collector collecting welding smoke from manufacturing area.
•

  14. Ducted Robotic Welding Cells

  Robotic weld cells ducted to central weld smoke collector.
•

  15. Cartridge Dust Collector for Robotic Welding

  Airex DCCH-12 cartridge dust collector collecting welding smoke from (2) robotic weld cells.
•

  16. Robotic Welding Canopy Hoods & Collectors

  Two (2) Airex Model DCCH-4 Dust Collectors ducted to two (2) Genesis RCT Robots with canopy hoods collecting welding smoke.
•

  17. Collector for Soldering Smoke #1

  Airflow Systems Model DC-18 Dust Collector collecting solder smoke from several solder pot stations.
•

  18. Collector for Soldering Smoke #2

  Airflow Systems Model DC-18 Dust Collector shown with ductwork connected to (9) solder pots.
•

  19. Collector for Soldering Smoke #3

  A solder pot that creates smoke when dipping cable with connector into it.
•

  20. Boom & Capture Arm Assembly #1

  Airflow Systems 16ft. boom with a 10ft. flexible arm assembly connected to a 3hp motor /blower assembly collecting welding smoke.
•

  21. Boom & Capture Arm Assembly #2

  A close up of welding smoke being collected by a Airflow System sourcecapture arm assembly.
•

  22. Central Cartridge Dust Collector #1

  Airex DCCH 32 cartridge dust collector collecting welding smoke from welding booths and robotic welders.
•

  23. Central Cartridge Dust Collector #2

  Motoman robotic welder and small welding booths connected to ductwork going to a Airex DCCH 32 cartridge duct collector located outside the building.
•

  24. Portable for Stainless Steel Welding

  Airflow Systems model PCH-2 portable self cleaning cartridge air cleaner with hepa final filter for collecting stainless steel / hexavalent chromium welding smoke.
•

  25. Downdraft Table

  Airflow Systems Model DT - 3000 down draft table collecting welding smoke.
•

  26. Dual Arm Portable Air Cleaner

  Airflow Systems Model Pac - 91 (Dual Arm) portable air cleaner collecting welding smoke from two welding stations.
•

  27. Central Collector

  Airex model DCCH30-40, 30 cartridge 40 hp 12,000 cfm central weld smoke collector ducted to twelve source capture arms.
•

  28. Flexible Arm & Boom Extension

  Weld smoke collection using flexible extraction arm and extension boom connected to Airex model DCCH30-40 central weld smoke collector.
•

  29. Long Boom / Flexible Arm

  Airflow Systems 16ft Boom with a 14ft Flexible Arm connected to a 3 HP Motor/Blower Assembly collecting weld smoke out of the breathing zone of the welder.
•

  30. Air Cleaners/Arms - Multiple Stations

  Airflow Systems Model HC 4 Air Cleaners collecting welding smoke from (10) welding stations.
•

  31. Weld Smoke Extractor Gun #1

  Henlex Air Mig weld smoke extraction gun collecting weld smoke out of the breathing zone of the welder.
•

  32. Weld Smoke Extractor Gun #2

  Close-up of Henlex Air Mig weld smoke extraction gun collecting weld smoke.
•

  33. Ambient Air Cleaners #1

  AFS Model F70-R Air Cleaners (Free-Hanging) collecting welding smoke from a fabrication area.
•

  34. Ambient Air Cleaners #2

  (4) Airflow Systems Model TC-4 (Free-Hanging) Air Cleaners collecting welding smoke.
•

  35. Boom / Extractor Arm

  Airflow Systems 10 ft. boom and 10 Flexible Extractor Arm Assembly collecting welding smoke from a welder's breathing zone.
•

  36. Central System - Flexible Extractor Arms

  Several Airflow Systems Flexible Extractor Arm Assemblies connected with duckwork to a Filter 1 Cartridge Dust Collector located outside the building.
•

  37. Central System - Exterior Collector

  A Filter 1 PFV-16-25 Dust Collector installed outside collecting welding smoke from 8 source capture arm assemblies.
•

  38. Robotic Welding Hood & Collector

  Airflow Systems Model DC-8 Dust Collector collecting smoke from a welding robot.
•

  39. Remote-Mounted

  Airflow Systems Model HC-4 Air Cleaner with (2) remote mounted flexible extractor arm assemblies collecting welding smoke.
•

  40. Portable Air Cleaner

  Airflow Systems Model PCH-1 Portable Air Cleaner collecting welding smoke.
•

  41. Extractor Arm & Air Cleaner

  Airflow Systems Model HC-4 Air Cleaner extracting welding smoke out of the breathing zone of the welder.
•

  42. Ambient Air Cleaner #1

  Airflow Systems Model TC-4 Air Cleaner (Free-Hanging) collecting welding smoke.
•

  43. Ambient Air Cleaner #2

  Airflow Systems Model TC- 4 (Free-Hanging) Air Cleaner collecting welding smoke.
•

  44. Boom / Flexible Arm Assembly

  Airflow Systems Model DCH- 2 Dust Collector connected to a 5 ft. boom arm with a 14 ft flexible arm assembly collecting welding smoke.
•

  45. Portable Booth

  Airflow Systems Portable Power Booth collecting welding smoke.
•

  46. Central High Vacuum for Extraction Guns

  A Henlex Central Vacuum Cleaning System installed outside the building collecting welding smoke from 12 mig smoke extraction guns.
•

  47. Extractor Gun

  A Henlex mig smoke fume extractor gun removing smoke from a welder's breathing zone.
•

  48. Flexible Arms

  Several Plymovent KUA-3 flexible arm assemblies collecting welding smoke.
•

  49. Central Collection System

  A Polaris Model 4PC64 Dust Collector collecting welding smoke from 24 welding stations.
•

  50. Robotic Welding #1

  Ductwork running to (5) welding robots into a central dust collection system located outside the building.
•

  51. Robotic Welding #2

  Clean Air America Model DFC-60 Dust Collector collecting smoke from (5) welding robots.
•

  52. Downdraft Bench

  Airflow Systems Model DT-3000 Down Draft Bench collecting welding smoke.
•

  53. Boom / Extractor Arm

  Airflow Systems 10 ft. boom, 14 ft. extractor arm connected to a 3 hp. fan exhausting welding smoke outside the building.
•

  54. Downdraft Booth

  Airflow Systems Model DCB-3 Power Booth collecting welding smoke out of the breathing zone of the welder.
•

  55. Extractor Arm #1

  Weld Smoke Collection using Flexible Extraction Arm Assembly
•

  56. Extractor Arm #2

  Weld Smoke Collection using Flexible Extractor Arm Assembly connected to Airflow Model HC-4 Air Cleaner.
