  1. Mist & Smoke Collection

  Airflow Systems Mist Collector PRO-2 collects coolant mist and smoke.
•

  2. Central Collection for Lathes #1

  Absolent A-Smoke 40 with ductwork connecting to seven Turno lathes.
•

  3. Central Collection for Lathes #2

  Absolent A-Smoke 40 collecting oil smoke and mist from Turno lathes.
•

  4. Central Collection for Lathes #3

  Absolent A-Smoke 40 connected to seven Turno lathes, collecting oil smoke and mist.
•

  5. Continuous-Duty Mist Collection

  Airflow Systems Mist PAC PRO-2 collecting coolant mist and smoke running 24/7.
•

  6. Haas Machining Center

  Airflow Systems Mist-Pac collecting mist from a Haas Machining Center hanging from the ceiling. Also shown in this photo is a Airflow Systems Model AHL-1 Downdraft table collecting aluminum grinding dust.
•

  7. Mist Collector for Two Grinders

  Airflow Systems MP-30 mist collector used to collect coolant mist from (1) OD grinder and (1) centerless grinder.
•

  8. Turnings Crusher #1

  Heavy duty air cleaners for extremely heavy smoke from a turnings crusher.
•

  9. Turnings Crusher #2

  Canopy hoods mounted over a turnings crusher with side curtains to collect the smoke from the crusher and the material on the conveyor belt.
•

  10. O-D Grinding Machine

  Airflow Systems Model MPH-8 mist collector collecting coolant mist from an O-D grinding machine.
•

  11. Surface Grinder Mist Collector #1

  Airflow Systems MP 30 mist collector ducted to a large surface grinder to collect the coolant mist spray coming off the wheel.
•

  12. Surface Grinder Mist Collector #2

  Custom built hood stays stationary as the 7' table passes under it and collects the coolant mist.
•

  13. Central Collection for CNCs

  An Airflow Systems MP120 mist collector, ducted to (5) CNC machines running 24/7 collecting coolant mist and smoke.
•

  14. Machining of Cast Iron Parts #1

  Airflow Systems Model F720 mist collectors moving 10,000 CFM each. These units are collecting coolant mist from large machining operations of cast iron parts.
•

  15. Machining of Cast Iron Parts #2

  A large cast iron part being machined and creating coolant mist. The mist is collected through the back of the machine enclosure and is being ventilated by an Airflow Systems Model F720 mist collector.
•

  16. Electronic Air Cleaner

  Trion Model T5200 (Double-Pass) Electronic Air Cleaner collecting oil mist and smoke from (12) Wire Draw Machines.
•

  17. Containment & Filtration for Grinding #1

  Airflow Systems Model 2400-VOM Air Cleaner is ducted to a canopy hood with curtains on all four sides to collect oil mist and smoke from a 14 inch grinding wheel.
•

  18. Containment & Filtration for Grinding #2

  Airflow Systems Model 2400-VOM Air Cleaners collecting oil mist and smoke from two 14 inch grinding wheels.
•

  19. Machining Center #1

  Airflow Systems Model F480-VOM Mist and Smoke Collector ducted directly to an Ingersoll Machining Center.
•

  20. Machining Center #2

  Airflow Systems Model MP-4 mist and smoke collector mounted directly to several Citizen Machining Centers.
•

  21. Machining Center #3

  Airflow Systems Model MP-14 mist and smoke collector ducted directly to a Mazak Machining Center.
•

  22. Machining Center #4

  Airflow Systems Model MP-14 Mist and Smoke Collector mounted directly on top of two Mazek Machining Centers.
•

  23. Machining Center #5

  Airflow Systems Model MP- 4 Air Cleaner collecting oil mist from a DAEWOO ( Puma ) 230M Machine.
•

  24. Stamping Presses

  Several Airflow Systems Model F120 Mist and Smoke collectors collecting oil mist from several stamping presses.
•

  25. Ambient Air Filtration

  (2)Trion Model T-2600 Electronic Air Cleaners collecting oil mist and smoke from a factory.
•

  26. Roll Mill Operation

  Trion Model 75-207/207 Double Pass Electronic Air Cleaner with self-cleaning oil wash system collecting heavy oil smoke from a roll mill operation.
•

  27. Central Air Cleaner/Collector

  Trion Model T2600 Electronic Air Cleaner ducted to several machines collecting oil mist and smoke.
•

  28. Blanchard & CNC

  Airflow Systems Model MP-30 Mist Collector collecting mist from a Blanchard and CNC machines.
